: : PRODUCTS : :

All Geared Vertical Milling Machine

Model No. BM2 GV[AFR]E BM3 GV[ARE]E BM4 GV[AFR]E
Table: MM MM MM
Working Surface 1270 x 300 1400 x 330 1600 x 330
T-Slot No./Size 3.16 3.16 3.16
T-Slot Centre 70 80 80
Distance from Spindle Max/Min 450 510 600
Logintudinal Travel X 700 800 1000
Cross Travel 215 260 340
Vertical Travel 450 510 600
Feed:
Number of Feeds 18 18 18
Range of Longitudinal Feed/min. 23 - 420 23 - 420 23 - 420
Range of Cross Feed/min. 23 - 420 23 - 420 23 - 420
Range of Vertical Feed/min. 3 - 70 3 - 70 3 - 70
Number of Rapid Feed 1 1 1
Rapid Long & Cross/min. 1050 1050 1050
Rapid Vertical/min. 175 175 175
Spindle:
Number of spindle speeds 12 12 12
Range of Spindle Speeds 40 - 12 RPM 40 - 12 RPM 40 - 12 RPM
Spindle Taper ISO 40 ISO 40 ISO 40
Arbor Diameter 25.4s 27 27
Electrical:
Main/Feed/Coolant Motors 3/2/0.1 H.P 5/2/0.1 H.P 7.5/3/0.1 H.P
Distance Spindle:
Vertical Movement to Quill Feed 75 100 100
Centre to column Face 370 406 406
Shipping Dimensions:
Length x Width x Height [cm] 173 x 137 x 200 182 x 160 x 218 198 x 168 x 234
Net Weight [kg.] 2100 3200 3700
Gross Weight [kg.] 2600 3700 4300
